Application:
The automatic coffee bean granule packaging machine is designed for efficiently packing granule materials, including coffee beans, popcorn, shrimp chips, salt, sugar, rice, sunflower seeds, peanuts, beans, nuts, pistachios, peas, and instant oatmeal/cereal oats.
Suitable Package:
Gusset bag, back sealing bag, 3/4 side seal bag, pillow bag
Kindly reminder:
Please tell us the following information while you send us an inquiry. Base on your message, we will suggest the optimum solution to you for reference. Thank you.
1. Bag dimension
2. Bag weight
3. Your product
4. Bag shape
5. Bag material
Benefits & Features
Parameter
Benefits & Features
Videos:
Bag Shape Options:
1. Pillow bag
2. Gusset bag
3. Flat bottom stand up bag
4. Quad seal stand up bag
5. Brick shape bag
6. Bag with hanging hole
7. Bag with easy tear notch
Features:
1. Ensures fast, efficient, and cost-effective granule packaging.
2. Suitable for small granules like coffee beans, rice, beans, salt, sugar, and other free-flowing materials.
3. Space-saving structure, ideal for limited production areas.
4. Minimizes material loss and enhances operational safety.
5. Supports hand-hole bags, linked bags, and various custom bag types.
6. Equipped with an intuitive touch screen for easy operation and adjustments.
7. Ensures smooth and consistent packaging to meet high production demands.
8. Built for long-term use, meeting food safety and hygiene standards.
Application:
| Model | BP-320A | BP-380A | BP-420A | BP-520A | BP-720A |
| Packing size | W:50-150mm | W:70-200mm | W:80-200mm | W:90-250mm | W:110-350mm |
| L:50-200mm | L:50-300mm | L:50-300mm | L:80-350mm | L:100-420mm | |
| Packing speed | 20-60 bags/min | 10-60 bags/min | 15-80 bags/min | 30-80 bags/min | 10-60 bags/min |
| Range of measuring | 700ml | 150-1500ml | 150-1500ml | Max 1500ml | Max 4000ml |
| The max width of packing film | 320mm | 420mm | 420mm | 520mm | 720mm |
| Air consumption | 200L/min 0.6MPa | 200L/min 0.6MPa | 200L/min 0.6MPa | 200L/min 0.6MPa | 300L/min 0.8MPa |
| Main power/voltage | 2.7KW/220V 50-60Hz | 2.5KW/220V 50-60Hz | 2.2KW/220V 50-60Hz | 2.2KW/220V 50-60Hz | 4.0KW/220V 50-60Hz |
| Main power/voltage | 350KG | 450KG | 450KG | 450KG | 800KG |
| Dimension | (L)1100* (W)800*(H)1940mm | (L)1400*(W)970*(H)1700mm | (L)1400*(W)970*(H)1700mm | (L)1480* (W)1200*(H)1700mm | (L)1780*(W)1350*(H)2000mm |
| Film thickness | 0.04-0.10mm | ||||
| Bag making mode | Pillow-type bag, Standing bag, punching device, Link-bag device | ||||
| Bag making mode | POPP/CPP, POPP/VMCPP ,BOBB/PE, PET/VMPET/PE, PET/AL/PE, NY/PE, PET/PET | ||||
