Automatic 120g-5kg Steamed Bun Pastry Frozen Food Packaging Machine

Application:

This packaging machine is suitable for quick-frozen foods, dumplings, glutinous rice balls, fried dough sticks, meatballs, grilled sausages, fried chicken, steamed buns, snack puffed foods, shrimp crackers, corn flakes, nuts, peanuts, popcorn, cereal, melon seeds, petfood and dried fruits , agricultural and sideline products, grains, hardware accessories and other products packaging.

Kindly Reminder:

Please tell us the following information while you send us an inquiry. Base on your message, we will suggest the optimum solution to you for reference. Thank you.

1. Bag dimension

2. Bag weight

3. Your product

4. Bag shape

5. Bag material

Benefits & Features

Parameter

Benefits & Features

Videos:


Bag Shape Options:

1. Stick bag

2. Three side sealing sachet

3. Four side sealing sachet

4. Small pillow bag

5. Linked bag

6. Bag with hanging hole

7. Bag with easy tear notch


Features:

  1. The multi-head combined weigher enhances both metering speed and accuracy.

  2. A 7-inch touch screen ensures easy operation, with multiple language options available.

  3. The imported PLC system guarantees stable machine performance and easy parameter adjustments.

  4. The memory function can store up to ten sets of parameters, allowing for easy product changes.

  5. A separate PID temperature controller accommodates various packing materials.

  6. The multi-union roll film pulling system ensures smoother film running.

  7. The double servo film-dragging structure enables stable bag forming and perfect bag shapes.

  8. The sophisticated sealing framework ensures consistent bag sealing and cutting.

  9. The machine automatically completes filling, metering, bag forming, date printing, sealing, and packing.

  10. Low loss, labor-saving, and easy to operate and maintain.


Application:

Automatic 120g-5kg Steamed Bun Pastry Frozen Food Packaging Machine

ModelBP-320ABP-380ABP-420ABP-520ABP-720A
Packing sizeW:50-150mmW:70-200mmW:80-200mmW:90-250mmW:110-350mm
L:50-200mmL:50-300mmL:50-300mmL:80-350mmL:100-420mm
Packing speed20-60 bag/min10-60 bag/min15-80 bag/min30-80 bag/min10-60 bag/min
Range of measuring700ml150-1500ml150-1500mlMax 1500mlMax 4000ml
The max width of packing film320mm420mm420mm520mm720mm
Air consumption200L/min 0.6MPa200L/min 0.6MPa200L/min 0.6MPa200L/min 0.6MPa300L/min 0.8MPa
Main power/voltage2.7KW/220V 50-60Hz2.5KW/220V 50-60Hz2.2KW/220V 50-60Hz2.2KW/220V 50-60Hz4.0KW/220V 50-60Hz
Main power/voltage350KG450KG450KG450KG800KG
Dimension(L)1100* (W)800*(H)1940mm(L)1400*(W)970*(H)1700mm(L)1400*(W)970*(H)1700mm(L)1480* (W)1200*(H)1700mm(L)1780*(W)1350*(H)2000mm
Film thickness0.04-0.10mm



Bag making modePillow-type bag, Standing bag, punching device,Link-bag device
Bag making modePOPP/CPP,POPP/VMCPP,BOBB/PE,PET/VMPET/PE,PET/AL/PE,NY/PE,PET/PET
