Automatic Vertical Weighing Filling Pouch Bag Granule Packing Machine

Automatic Vertical Weighing Filling Pouch Bag Granule Packing Machine

Application:

The Bingopack Automatic Multihead Weigher Back Seal Pouch VFFS Packing Machine is designed for packing a variety of granules, sheets, strips, and irregular materials, such as candy, melon seeds, chips, peanuts, nuts, dried fruit, jelly, biscuits, and camphor balls, etc.

Kindly reminder:

Please tell us the following information while you send us an inquiry. Base on your message, we will suggest the optimum solution to you for reference. Thank you.

1. Bag dimension

2. Bag weight

3. Your product

4. Bag shape

5. Bag material

Inquire Now WhatsApp

Benefits & Features

Parameter

Benefits & Features

Videos:

Bag Shape Options:

1. Pillow bag

2. Gusset bag

3. Quad seal bag

4. Link bag

5. Bag with hanging hole

6. Bag with easy tear notch

Features:

1. Hygienic and Safe Design: The equipment is constructed from 304 stainless steel and complies with QS food standards and GMP pharmaceutical hygiene guidelines. It includes built-in safety features to align with corporate safety standards.

2. Precision Temperature Control: An independent control system provides precise temperature regulation, ensuring each seal is smooth and visually appealing.

3. Smart Operation: Utilizing servo motor film handling, PLC, and touch screen control, the machine delivers automated, high-speed, and intelligent operation for reliable performance.

4. Automated Adjustments: The double-belt film feeding and color code alignment systems can be fine-tuned automatically through the touch screen, simplifying adjustments and correction of sealing or cutting deviations.

5. Multi-Product Compatibility: The interface stores preset parameters for different packaging processes, enabling quick, easy transitions between products without manual reconfiguration.

6. Customizable Flexibility: Tailored options make this equipment adaptable to specific requirements across various food and pharmaceutical products, enhancing versatility.

Application:

Model	BP-320A	BP-380A	BP-420A	BP-520A	BP-720A
Packing size	W:50-150mm	W:70-200mm	W:80-200mm	W:90-250mm	W:110-350mm
Packing size	L:50-200mm	L:50-300mm	L:50-300mm	L:80-350mm	L:100-420mm
Packing speed	20-60 bag/min	10-60 bag/min	15-80 bag/min	30-80 bag/min	10-60 bag/min
Range of measuring	700ml	150-1500ml	150-1500ml	Max 1500ml	Max 4000ml
The max width of packing film	320mm	420mm	420mm	520mm	720mm
Air consumption	200L/min 0.6MPa	200L/min 0.6MPa	200L/min 0.6MPa	200L/min 0.6MPa	300L/min 0.8MPa
Main power/voltage	2.7KW/220V 50-60Hz	2.5KW/220V 50-60Hz	2.2KW/220V 50-60Hz	2.2KW/220V 50-60Hz	4.0KW/220V 50-60Hz
Main power/voltage	350KG	450KG	450KG	450KG	800KG
Dimension	(L)1100* (W)800*(H)1940mm	(L)1400(W)970(H)1700mm	(L)1400(W)970(H)1700mm	(L)1480* (W)1200*(H)1700mm	(L)1780(W)1350(H)2000mm
Film thickness	0.04-0.10mm
Bag making mode	Pillow-type bag, Standing bag, punching device,Link-bag device
Bag making mode	POPP/CPP,POPP/VMCPP,BOBB/PE,PET/VMPET/PE,PET/AL/PE,NY/PE,PET/PET
