Application:
This Automatic Powder Pouch Packing Machine is widely used in industries such as food, pharmaceuticals, chemicals, and agriculture. It is ideal for packaging powdered products like spices, milk powder, protein powder, flour, chemical powders, and fertilizers into pouches of various sizes, ensuring precise dosing and efficient packaging.
Kindly reminder:
Please tell us the following information while you send us an inquiry. Base on your message, we will suggest the optimum solution to you for reference. Thank you.
1. Bag dimension
2. Bag weight
3. Your product
4. Bag shape
5. Bag material
Benefits & Features
Parameter
Benefits & Features
Videos:
Bag Shape Options:
1. Pillow bag
2. Gusset bag
3. Flat bottom stand up bag
4. Quad seal stand up bag
5. Brick shape bag
6. Bag with hanging hole
7. Bag with easy tear notch
Features:
1. The equipment frame is made of food-grade 304 stainless steel for enhanced safety protection. It features an independent temperature control system, ensuring accurate temperature regulation and a smooth, aesthetically pleasing seal.
2. Equipped with a servo motor for film pulling, the machine is controlled by PLC and a touch screen, offering automatic control, high reliability, intelligence, speed, and efficiency.
3. The touch screen allows for automatic adjustment to correct sealing and cutting deviations, making operation simple and user-friendly.
4. It can store multiple packaging process parameters for different products, enabling seamless product changes without needing adjustments.
5. The machine is equipped with a fault display system, facilitating timely troubleshooting and reducing the need for manual operation.
6. Various bag types, such as pillow bags, pin bags, hanging hole bags, and custom bags, can be produced according to customer requirements.
7. The machine features a fully enclosed mechanism to prevent dust from entering the device.
Application:
Model | BP-320D | BP-420D | BP-520D |
Film Width | Max.320mm | Max.420mm | Max.520mm |
Filling Range | 150-800ml | 150-1500ml | 150-2000ml |
Bag Length | 80-240mm | 80-300mm | 80-350mm |
Bag Width | 50-150mm | 60-200mm | 80-250mm |
Packaging Speed | 5-70 bags/min | 5-60 bags/min | 10-50 bags/min |
Machine Power | 220V, 50/60HZ, 2KW | 220V, 50/60HZ, 2.2KW | 220V, 50/60HZ, 3KW |
Machine Size（L*W*H） | 1185*935*1245mm | 1217*1015*1343mm | 1488*1080*1490mm |
Machine Weight | 550KG | 650KG | 750KG |
